Study Notes for Microsoft Exam: Developing ASP.NET MVC Web Applications (70-486)

Took Microsoft Exam 70-486 which part of MCSD certification. I spend about 2 weeks studying the material and took some notes which are posted here. Notes are not complete in the sense that they don’t cover the full syllabus – half of my notes are scattered in different places which will be incorporated here later (hopefully).

Code First Migrations:

Three step process (use Package Manager Console):

  1. enable-migrations -ContextTypeName MyProject.Models.StudentDBContext
    • Creates Configuration class with Seed method
    • Needs to be executed only once to setup migrations
  2. add-migration MyFirstMig
    • Creates {DateStamp}_MyFirstMig.cs in Migrations folder
    • Execute it after each change to model
  3. update-database
    • Execute it to apply changes to database

Data Annotations:

  • [Required]
  • [Range(5, 10)]
  • [StringLength(5)]
  • [DataType(DataType.Date)]         (enum DataType { CreditCard, Currency, Custom, Date, DateTime, Duration, EmailAddress, Html, ImageUrl, MultilineText, Password, PhoneNumber, PostalCode, Text, Time, Upload, Url, })
  • [DisplayFormat(DataFormatString = “{0:d}”)]

Model Validation:

  • In Controller’s Create or Edit action (server):
[HttpPost]
public ActionResult Create(Movie movie)
{
   if (ModelState.IsValid)
   {
      db.Movies.Add(movie);
      db.SaveChanges();
      return RedirectToAction("Index");
   }

   return View(movie);
}
  • In view (browser):
<div class="editor-field">
   @Html.EditorFor(model => model.Title)
   @Html.ValidationMessageFor(model => model.Title)
</div>

Cross Site Scripting Attack

  • Add @AntiForgeryToken() in view inside form element
  • Add [ValidateAntiForgeryToken] attribute on form post actions

Asynchronous Programming with async and await:


Bundling and Minification

  • Good Article: Link
  • Most browsers limit the number concurrent requests to the same domain to six
  • To disable
<system.web>
    <compilation debug="true" />
    <!-- Lines removed for clarity. -->
</system.web>
  • Can be overwritten in code
BundleTable.EnableOptimizations = true;
  • Creating script bundle
bundles.Add(new ScriptBundle("~/bundles/jquery").Include(
                 "~/Scripts/jquery-{version}.js"));
  • Creating style bundle
bundles.Add(new StyleBundle("~/Content/themes/base/css").Include(
          "~/Content/themes/base/jquery.ui.core.css",
          "~/Content/themes/base/jquery.ui.resizable.css",
          "~/Content/themes/base/jquery.ui.selectable.css",
          "~/Content/themes/base/jquery.ui.accordion.css" ));
  • Adding reference to bundles in view
@Styles.Render("~/Content/themes/base/css", "~/Content/css")
@Scripts.Render("~/bundles/modernizr")

<script src='@Scripts.Url("~/bundles/modernizr")' async> </script>



  • Can use ‘*’ wildcard and IncludeDirectory function
bundles.Add(new StyleBundle("~/jQueryUI/themes/baseAll")
    .IncludeDirectory("~/Content/themes/base", "*.css"));
  • .min files are selected for release (jquery-1.7.1.min.js)
  • -vsdoc files are ignored (they are for intellisense)
  • Bundle Transformation
    • Implement IBundleTransform
using System.Web.Optimization;

public class LessTransform : IBundleTransform
{
    public void Process(BundleContext context, BundleResponse response)
    {
        response.Content = dotless.Core.Less.Parse(response.Content);
        response.ContentType = "text/css";
    }
}
  • Add transformation
var lessBundle = new Bundle("~/My/Less").IncludeDirectory("~/My", "*.less");
lessBundle.Transforms.Add(new LessTransform());
lessBundle.Transforms.Add(new CssMinify());
bundles.Add(lessBundle);

Using OAuth providers with MVC:

  • Register your site with provider and Receive parameters (such as key or id, and secret)
  • Register your application as Provider’s client: RegisterFacebookClient(            appId: “111111111111111”,            appSecret: “a1a1aa111111111a111a111aaa111111”);

Interaction among View, Layout page (_Layout.cshtml) and other pages

@RenderBody() Called from _Layout.cshtml to render the body of the requested page at the right place within layout.
@RenderSection(“scripts”, required: false) Called from _Layout.cshtml to rendor a section if defined in the requested page.- Section definition is optional if required is false- Section definition on requested page

@section Scripts {

   @Scripts.Render(“~/bundles/jqueryval”)

}

@RenderPage(“MyView.cshtml”, MyModel) Renders the specified page as part of the requested page. Similar to @Html.Partial(“MyView”)



WCF vs ASP.Net Web API


Others

  • Don’t use HTTP GET request for delete, edit or create options as they open security holes (link)
  • Fiddler, a web debugging tool which logs all HTTP / HTTPS traffic. (http://www.telerik.com/fiddler/)

Authorization

  • [Authorize(Roles=”Admin,PowerUser“, Users=”Mark“)]
    • Implements IAuthorizationFilter which has one method OnAuthorization
  • AuthorizeAttribute.AuthorizeCore method: When overridden, provides an entry point for custom authorization checks.
  • [AllowAnonymous] This attribute on Action will override the Authroize on Controller and wise versa



Browser / Feature Detection and Compatibility

  • Video tab with fall backs
<video>
<source src="video.mp4" type='video/mp4' />
<source src="video.webm" type='video/webm' />
<object type="application/x-silverlight-2">
<param name="source" value="http://url/player.xap">
<param name="initParams" value="m=http://url/video.mp4">
</object>
Download the video <a href="video.mp4">here</a>.
</video>



  • Display modes (by default we have regular mode and Mobile mode)
    • Mobile.cshtml will be used instead of Index.cshtml automatically when page is accessed through a mobile
    • Add new DefaultDisplayMode (WP7.cshtml)



DisplayModeProvider.Instance.Modes.Insert(0, new DefaultDisplayMode("WP7")
  {
      ContextCondition = ctx => ctx.GetOverriddenUserAgent().Contains("Windows Phone OS")
  });



  • Setting viewport to device width <meta name=”viewport” content=”width=device-width” />
  • CSS @media query



@media only screen and (max-width: 850px) {
    .site-title {
        color: #c8c8c8;
    }
}

@media (min-width: 768px) and (max-width: 979px) and (orientation:portrait) {…



  • Check if user is on mobile device: Browser.IsMobileDevice
  • CSS Vendor Prefixes
    • -ms-, -mso- (Mircosoft); -moz- (Mozilla); -webkit- (Apple, Google); -o-, xv- (Opera)
    • Example: -moz-border-radius: 18px;



Razor View Templates



  • EditorFor template (used with @Html.EditorFor() helper)
    • Path: ~/Views/ControllerName/EditorTemplates/Article.cshtml



@model MyMVCApplication1.Article
@if (Model != null)
{
    @Html.TextBox("", Model.Title)
    @Html.TextBox("", Model.Body)
}
else
{
    @Html.TextBox("", string.Empty)
    @Html.TextBox("", string.Empty)
}



  • DisplayTemplate (used with @Html.DisplayFor() helper)
    • Path: ~/Views/ControllerName/DisplayTemplates/<Type Name>.cshtml



Action Filters



    • Authorization filters – Implements the IAuthorizationFilter attribute.
    • Action filters – Implements the IActionFilter attribute.
    • Result filters – Implements the IResultFilter attribute.
    • Exception filters – Implements the IExceptionFilter attribute.
  • Authorization filters are always executed before action filters
  • Filter’s Order parameter can be used to control the order in which filters of same type are executed
  • Filter’s AllowMultiple parameter can be used to run filter only once
  • ActionFilterAttributeimplements bothIActionFilter andIResultFilter and drives fromActionFilterAttribute
    • It has methods: OnActionExecuting, OnActionExecuted, OnResultExecuting, OnResultExecuted
  • Add filter globally to all actions Add(new RequireHttpsAttribute());
    • filters is GlobalFilters.Filters passed as parameter to FilterConfig
  • Useful Fitlers: HandlerError, OutputCache, Authorize



Web Accessibility Initiative-Accessible Rich Internet Applications (WAI-ARIA)

  • aria-labelledby=”name_label” This attribute on input field can an link it to the label which can deliver meaning otherwise delivered visually
  • aria-required defines a mandatory input field



Search Engine Optimization

  • txt file – create robot exclusion rules (list pages that should be indexed by search engine)
  • Have meaningful url. Rather than com/1, use mysite.com/<record title>



Globalization

  • Accept-Language: en-US,en;q=0.8 (Request Header presented to server)
  • en is Language, US is Locale. Language is at a higher level than locale.
  • <globalization culture=”auto” uiculture=”auto” enableclientbasedculture=”true”/> (enable client based culture in Web.Config)
  • Thread.CurrentThread.CurrentUICulture (find current culture)
  • Use resource files
    • keeps strings in resource files (.resx)
    • create separate files for each language (MyResFile.resx, MyResFile.es-MX.resx)
    • access string using MyResFile.MyLabel1
  • An Alternative to resource files is to use localized views
  • There no way to determine culture in javascript (server has to send it back)
  • Setting culture for jQuery in browser (use anyone of the two)
    • <script>preferCulture(language);</script>
    • $.global.preferCulture(language)
  • Manually set culture on server (may be based on user selection)
    • CurrentThread.CurrentUICulture = new CultureInfo(“es-MX”);
  • Create satellite assemblies (dll) to separate culture specific resouces (only required resources are loaded in memory)



Action Attributes (other than filters and attributes covered in else where)

  • RequireHttps
  • ValidateInputTo exclude a field [ValidateInput(true, Exclude = “ArbitraryField”)]
  • AllowHtml
  • ActionName
  • ChildActionOnly (action can’t be accessed directly by client, has to be called from a view using @Html.Action(“MyView”) or RenderAction )



Error Handling

  • [HandleError(ExceptionType=typeof(NullReferenceException), View=”MyErrorView”)]
    • Action attribute for handling exception
    • Implements IExceptionFilter that has OnException method
    • By default MVC display ~/Views/Shared/Error
  • Application_Error method in global.asax class (for unhandled exception that makes through the stack)
  • IsCustomErrorEnabled

Action Results

  • All action results derive from ActionResult class
Action Result Type Action Helper method Comments
ViewResult View Renders Html, derive from ViewBaseResult
PartialViewResult PartialView Renders Html, derive from ViewBaseResult
JsonResult Json
JavaScriptResult JavaScript
RedirectResult Redirect
RedirectToRouteResult RedirectToActionRedirectToRoute
FileResult File
ContentResult Content Can be used to return pdf, xml etc.
EmptyResult N/A (return null)



  • A custom action result can be created by inheriting from ActionResult class and overriding void ExecuteResult(ControllerContext ctx) method

Model Binders

  • DefaultModelBinder Maps a browser request to a data object
  • LinqBinaryModelBinder Maps a browser request to a LINQ object
  • Creating a custom model binder
  • Implement IModelBinder interface with one method: public object BindModel(ControllerContextcontrollerContext,ModelBindingContextbindingContext)
  • Setting custom binder for a model class
[ModelBinder(typeof(MyModelBinder))]
public class MyModel
{       ...     }
  • Another way of doing it

ModelBinders.Binders.Add(typeof(MyModel),newMyModelBinder())



  • Extending DefaultModelBinder class
    • public class MyBinder : DefaultModelBinder
  • Extend BindProperty method (loops through every model property one by one)
    • protected override void BindProperty(ControllerContext contContext, ModelBindingContext bindContext, PropertyDescriptor propDesc)
    • can be used to override default behavior for certain properties e.g. combine date and time from two fields into one property
    • call base.BindProperty for properties you want to bind using default binding
  • Registor the new binder

ModelBinders.Binders.DefaultBinder =newMyBinder();



  • Weakly typed model, all parameter with login prefix will map to LoginUser model

public ActionResult Login([Bind(Prefix=”login”)]LoginUser user)

  • Exclude / Include paramters for Bind

public ActionResult Save([Bind(Exclude = “Salary”)]Employee emp)



  • Four value providers: FormsValueProvider, QueryStringValueProvider, HttpFileCollectionValueProvider, RouteDataValueProvider
  • Three types of model binding: Strong, Weak and using ValueProvider.



Routes

  • Defining routes (IgnoreRoute should come before MapRoute)
public static void RegisterRoutes(RouteCollection routes)
        {
            routes.IgnoreRoute("{resource}.axd/{*pathInfo}");
            routes.MapRoute(
            name: "Default",
            url: "{controller}/{action}/{id}",
            defaults: new
            {
                controller = "Home",
                action = "Index",
                id = UrlParameter.Optional
            },
            constraints: new { id = @"\d+" }
            );
        }



  • In case of Areas, providing a link to action

@Html.ActionLink(“Exam Detail”, “Exam”, “Detail”, new { area=”ExamSite”}, null)



  • Extending default MvcRouteHandler
    • public class MyCustomRouteHandler : MvcRouteHandler
    • Override protected override IHttpHandler GetHttpHandler(RequestContext reqContext)
    • Registering route handler
routes.MapRoute(
                "Home",
                "{controller}/{action}",
                new { controller = "Home", action = "Index" }
                ).RouteHandler = new MyCustomRouteHandler();
  • Implementing IRouteHandler (has one method GetHttpHandler)
    • Registration is bit different from above

Route customRoute = new Route(“custom/{name}”, new MyRouteHandler(“My Route”));

routes.Add(“route-name”, customRoute);

ControllerFactory

  • For custom controller factory, implement IControllerFactory which has three methods: CreateController, ReleaseController, and GetControllerSessionBehavior.
  • Register controller factory in the Global.asax Application_Start method: ControllerBuilder.Current.SetControllerFactory(typeof(MyControllerFactory());
  • Link: Deep Drive into IControllerFactory

View Engine

  • Both RazorViewEngine and Web Forms engine derive from VirtualPathProviderViewEngine which in turn implements IViewEngine
  • IViewEngine has three methods: FindView, FindPartialView and ReleaseView
  • The two find methods return ViewEngineResult object which contains IView
  • IView has one method public void Render(ViewContext viewContext, System.IO.TextWriter writer)

MVC Life Cycle

  • Request
  • UrlRoutingModule selects the Route object
  • Based on the route, UrlRoutingModule obtains an object that implements IRouteHandler (typically it is MvcRouteHandler)
  • MvcRouteHandler creates an instance of MvcHandler which implements IHttpHandler
  • MvcHandler obtains reference to IControllerFactory (typically DefaultControllerFactory)
  • MvcHandler create Controller instance by help of IControllerFactory
  • MvcHandler calls controller’s Execute method
  • ControllerActionInvoker object associated with Controller determines which action method to call
  • Response
  • Controller action create ViewResult
  • ViewResult calls ViewEngine
  • ViewEngine calls View
  • View renders the Response

HTTP Handlers

  • Implement IHttpHandler which has a method ProcessRequest and a property IsReusable
  • Register handler
      <system.web>
        <httpHandlers>
          <add verb="*" path="SampleHandler.new" type="SampleHandler" />
          <add verb="*" path="*.SampleFileExtension" type="SampleHandler2 " />
        </httpHandlers>
      </system.web>

Http Modules

    <system.web>
      <httpModules>
        <add name="HelloWorldModule" type="HelloWorldModule"/>
      </httpModules>
    </system.web>

Windows Identity Foundation

Convert C# code to JavaScript

There are some tools which convert C# code to JavaScript. Obviously these will only be useful if your code is not tightly coupled with any C# library as the library won’t be available in JavaScript. These conversion tools may come handy for model classes or any other logic which is, for the most part, independent of .Net framework classes.

The main focus of these tools is not code conversion, rather they primarily try to do for C# what GWT does for Java. They allow you to write code in C#, access the DOM and JavaScript libraries to develop web applications. When the code is compiled, the output is not .Net Application but a web application written in JavaScript and HTML.



Conversion Tool Description
duocode duocode is a new tool on the block, currently in beta. It is going to be a commercial software but free to use as of now. duocode uses Microsoft Roslyn and support debugging C# code your compiled JavaScript is running in the browser. It supports pretty comprehensive set of C# feature including Await/Async, C# 6.0 language features, resource files etc.

Homepage: http://duoco.de/

SharpKit SharpKit is commercial (free for open source & small projects) as opposed to the alternatives listed below but does an excellent job of converting C# to JavaScript which is clean and readable. Moreover, it supports all features of C# language.You can see SharpKit live in action here. Give it a C# class or a snippet, it will convert it to JavaScript right there.Sharpkit compares itself with JSC, Script# and GWT at http://sharpkit.net/Compare.aspx

Homepage: http://sharpkit.net/
Google Code: https://code.google.com/p/sharpkit/

JSIL JSIL is a compiler that transforms .NET applications and libraries from their native executable format (CIL bytecode) into standards-compliant, cross-browser JavaScript.There are quite a few demos on JSIL website, one of them allows you to convert C# code to JavaScript right in the browser (though the generated code looks a bit obscure).

Homepage: http://jsil.org/
GitHub: https://github.com/sq/JSIL

JSC JSC is an Open Source cross-compiler where you can create web applications for Java, JavaScript, Flash ActionScript, PHP and Google App Engine using Microsoft .NET in C#, VB or F#. And also integrates into the .NET frameworks, Silverlight and ASP.NET.

Homepage: http://www.jsc-solutions.net/
Wiki & Tutorials: http://wiki.jsc-solutions.net/
Sourceforge: http://sourceforge.net/projects/jsc/

Script# Script# is a compiler that generate the JavaScript instead of MSIL (Microsoft Intermediate Language) from C# source code like GWT (Google Web Toolkit).Script# supports a subset of language features, for instance enum and struct are not supported.

Homepage: http://scriptsharp.com/
GitHub Repository: https://github.com/nikhilk/scriptsharp

Saltarelle Saltarelle is an open source C# to JavaScript compiler. Saltarelle is not an entire framework for web application development (such as GWT), rather it consists of a compiler and a small runtime library that only contains the things necessary for the language features to work. It is, however, designed with interoperability in mind so you can use any existing JavaScript framework with it. It comes with support for jQuery, and other libraries can be used either by authoring an import library (which is just a class / set of classes with special attributes on their members) or by using they ‘dynamic’ feature of C# 4.

Homepage: http://www.saltarelle-compiler.com/
Git Repository: https://github.com/erik-kallen/SaltarelleCompiler

For a comprehensive list of tools that convert C# and other languages to JavaScript, visit https://github.com/jashkenas/coffee-script/wiki/List-of-languages-that-compile-to-JS

How to embed chrome browser in .net application

Chrome browser can be embedded in native application taking a hybrid approach to development where application is partly developed in native technology and partly in web. This has several advantages:

  • Salvage the existing investment in HTML/Javascript projects.
  • The part of application written in web technology is platform independent. This is very important due to variety of devices that are prevalent today.
  • Overcome the limitation of web technology and leverage the full power of the hardware through native code.

We need to know about three projects:

Project Type Description
Chromium Web Browser Chromium is the open source browser project which is behind Google Chrome.
ChromiumEmbedded
(CEF)
Web Browser Control Based on Chromium project, an open source embed-able Web Browser Control is developed called ChromiumEmbedded. ChromiumEmbedded supports programming interface for C++.
Xilium.CefGlue .Net Wrapper Quite a few wrappers are available to make ChromiumEmbedded accessible in other languages. The most updated and active wrapper for .Net is Xilium.CefGlue.

Follow the below steps to embed Chromium Web Browser control in your .Net application.

  1. Download the source code for Xilium from here (Click on the Branches tab and download the Master branch).
  2. Check for the current ChromiumEmbedded (CEF) build supported by Xilium here. As of now, the ChromiumEmbedded supported build is CEF 3.1547.1448. Download the relevant pre build binaries from here.
  3. Unzip the two downloaded files. Copy all DLLs from the Release folder of ChromuimEmbedded and place it in Debug folder of CefGlue.Demo.WinForms project in Xilium source code.
  4. Copy the locales folder under Resources from ChromuimEmbedded and place it in the Debug folder of CefGlue.Demo.WinForms project in Xilium source code.
  5. Open the Xilium source code in Visual Studio using Xilium.CefGlue.sln. Set CefGlue.Demo.WinForms as the startup project.
  6. Build and run the solution and you will get the demo .Net application running with embedded chromium browser.

Completed ‘HTML5 Game Development’ course from Udacity

I have been taking Massively Open Online Courses at Coursera, but this is the first one at Udacity. The two platforms take different approaches… Coursera is more like a virtual classroom while Udacity feels like a very well designed interactive tutorial. Udacity is self-paced with very short video clips interspersed with questions and quick programming assignments. On the other hand, courses at Coursera start at specific dates and the assignments have deadlines. All students of a batch enroll in the class at the same time and discuss same topics on forums as the course progresses. This gives a more real university classroom like structure to Coursera.

The ‘HTML5 Game Development’ course teaches basic skills to get started with 2D game development. It does that by going through techniques and tools that were used to develop GRITS. GRITS can be downloaded from here. The overall quality of the course could be improved, particularly the grader bugs in some of the assignments were frustrating. Still I had a good time, mainly because Udacity as a platform is great and going by the posts in discussion forums, rest of the computer science courses at Udacity have excellent content. I would be hooked on Udacity for some time 🙂

Following are the tools used or recommended during the course:

Creating Sprite Sheets http://www.codeandweb.com/texturepacker
Map Editor http://www.mapeditor.org/ (Tiled)
Physics Engine http://box2d.org/
Audio Editor http://www.goldwave.com/

HTML5 Game Development - Udacity-page-001

Passed Microsoft Exam 70-480: Programming in HTML5 with JavaScript and CSS3

There is huge interest in HTML 5 among the web development community these days. Once again there is hope that we can ‘write once, and run anywhere’ with the latest version of HTML. The ability to run your code anywhere is very significant considering the plethora of devices (from smart phone to TVs) that we use to access internet these days. HTML 5 is supposed to eliminate the need for browser plugins and to cut into the share of native applications.

I haven’t got to use HTML 5 yet in any of the projects but I have been closely following the development in this regard. Today I took the Microsoft exam for HTML 5 after going through couple of resources for preparation.

I enjoyed the format of the exam as it require you to complete code snippets, drag and drop code lines etc. in addition to the usual multiple choice questions.

Using XSL Variable and Axes to format XML data into HTML having elements grouped by a tag

Following XSL converts the xml data into a format where first tag of the element is converted into heading and all elements having the same value for first tag will appear in a table below that heading. The Xml elements must be sorted by first tag.

To understand the transformation, consider the following Xml:

<mydata>
 <contact>
   <name>Mark</name>
   <telephone>34546343</telephone>
   <description>Work</description>
 </contact>
 <contact>
   <name>Mark</name>
   <telephone>98884748</telephone>
   <description>Home</description>
 </contact>=
 <contact>
   <name>Mark</name>
   <telephone>23456123</telephone>
   <description>Mobile</description>
 </contact>
 <contact>
   <name>William</name>
   <telephone>23098764</telephone>
   <description>Mobile</description>
 </contact>
 <contact>
   <name>William</name>
   <telephone>45645356</telephone>
   <description>Work</description>
 </contact>
</mydata>

The XSL generates the following output:

Contact: Mark

Telephone Description
34546343 Work
98884748 Home
23456123 Mobile

Contact: William

Telephone Description
23098764 Mobile
45645356 Work

XSL is following:

<?xml version="1.0" encoding="utf-8"?>
<xsl:stylesheet version="1.0" xmlns:xsl="http://www.w3.org/1999/XSL/Transform"
 xmlns:msxsl="urn:schemas-microsoft-com:xslt" exclude-result-prefixes="msxsl"
>
 <xsl:template match="/">
 <html>
   <body>
     <xsl:for-each select="mydata/contact">
       <xsl:if test="name != preceding-sibling::contact&#91;1&#93;/name or position() = 1">

        <H3>
         Contact: <xsl:value-of select="name"/>
         </H3>

         <table border="1">
         <tr bgcolor="#9acd32">
           <th>Telephone</th>
           <th>Description</th>
         </tr>

        <xsl:apply-templates select="."/>

        <xsl:variable name="curObject" select="name"/>
         <xsl:apply-templates select="following-sibling::contact&#91;name = $curObject&#93;"></xsl:apply-templates>


         </table>
       </xsl:if>
     </xsl:for-each>

  </body>
 </html>
 </xsl:template>

 <xsl:template match="contact">
   <tr>
     <td> <xsl:value-of select="telephone"/></td>
     <td> <xsl:value-of select="description"/></td>
   </tr>
 </xsl:template>
</xsl:stylesheet>
